Model
|
Part No. NPT
|
Part No. BSP
|
Flow Rate
|
Feed Ratio
|
Operating Pressure
|
Inlet/Outlet Pipe Connection
|
|
Min.
|
Max.
|
Min.
|
Max.
|
|
A10-10%
|
112011
|
|
0.20 gpm
|
10 gpm
|
1.0%
|
10.0%
|
10.0-65 psi
|
3/4 npt
|
|
|
112111
|
1,89 lpm
|
38 lpm
|
1:100
|
1:10
|
0,69-4,5 bar
|
3/4 bsp
|
|
A12-2.5%
|
112421
|
|
0.03 gpm
|
12 gpm
|
0.5%
|
2.5%
|
6.0-100 psi
|
3/4 npt
|
|
|
112431
|
0,11 lpm
|
45 lpm
|
1:200
|
1:40
|
0,41-6,9 bar
|
3/4 bsp
|
|
A12-5%
|
112441
|
|
0.03 gpm
|
12 gpm
|
1.0%
|
5.0%
|
6.0-100 psi
|
3/4 npt
|
|
|
112451
|
0,11 lpm
|
45 lpm
|
1:100
|
1:20
|
0,41-6,9 bar
|
3/4 bsp
|
|
Mobile for A10, A12 Units
|
011610
|
011610
|
|
|
|
|
|
|
|
A15TF-4ml
|
113524
|
|
0.04 gpm
|
15 gpm
|
0.025%
|
0.4%
|
3.0-60 psi
|
3/4 hose/1 npt
|
|
|
113525
|
0,15 lpm
|
57 lpm
|
1:4000
|
1:250
|
0,21-4,1 bar
|
3/4 bsp/1 bsp
|
|
A15TF-2.5%
|
113004
|
|
0.04 gpm
|
15 gpm
|
0.2%
|
2.5%
|
3.0-60 psi
|
3/4 hose/1 npt
|
|
|
113504P
|
0,15 lpm
|
57 lpm
|
1:500
|
1:40
|
0,21-4,1 bar
|
3/4 bsp/1 bsp
|
|
A20-10%
|
113108
|
|
2.0 gpm
|
20 gpm
|
2.0%
|
10.0%
|
5.0-55 psi
|
3/4 hose/1 npt
|
|
|
113608
|
7,6 lpm
|
76 lpm
|
1:50
|
1:10
|
0,34-3,8 bar
|
1: bsp/1 bsp
|
|
A30-4ml
|
113105P
|
|
0.15 gpm
|
30 gpm
|
0.025%
|
0.4%
|
5.0-100 psi
|
3/4 hose/1 npt
|
|
|
113605P
|
0,57 lpm
|
114 lpm
|
1:4000
|
1:250
|
0,34-6,9 bar
|
3/4 bsp/1 bsp
|
|
A30-2.5%
|
113102P
|
|
0.15 gpm
|
30 gpm
|
0.2%
|
2.5%
|
5.0-100 psi
|
3/4 hose/1 npt
|
|
|
113602P
|
0,57 lpm
|
114 lpm
|
1:500
|
1:40
|
0,34-6,9 bar
|
3/4 bsp/1 bsp
|
|
A30-5%
|
113107P
|
|
0.15 gpm
|
30 gpm
|
0.4%
|
5.0%
|
5.0-100 psi
|
3/4 hose/1 npt
|
|
|
113607P
|
0,57 lpm
|
114 lpm
|
1:250
|
1:20
|
0,34-6,9 bar
|
3/4 bsp/1 bsp
|
|
A40-4ml
|
113106P
|
|
0.50 gpm
|
40 gpm
|
0.025%
|
0.4%
|
5.0-100 psi
|
1-1/2 slip
|
|
|
113606P
|
1,89 lpm
|
151 lpm
|
1:4000
|
1:250
|
0,34-6,9 bar
|
50 mm slip/bsp
|
|
A40-2.5%
|
113103P
|
|
0.50 gpm
|
40 gpm
|
0.2%
|
2.5%
|
5.0-100 psi
|
1-1/2 slip
|
|
|
113603P
|
1,89 lpm
|
151 lpm
|
1:500
|
1:40
|
0,34-6,9 bar
|
50 mm slip/bsp
|
|
Mobile for A30 & DP30
|
011809
|
011809
|
|
|
|
|
|
|
|
A80-4ml
|
011808ml
|
|
1.0 gpm
|
80 gpm
|
0.025%
|
0.4%
|
5.0-100 psi
|
2 slip
|
|
|
011808ml
|
3,8 lpm
|
303 lpm
|
1:4000
|
1:250
|
0,34-6,9 bar
|
63 mm slip/bsp
|
|
A80-2.5%
|
011808
|
|
1.0 gpm
|
80 gpm
|
0.2%
|
2.5%
|
5.0-100 psi
|
2 slip
|
|
|
011808
|
3,8 lpm
|
303 lpm
|
1:500
|
1:40
|
0,34-6,9 bar
|
63 mm slip/bsp
|
|
DP30-2.3%
|
011381
|
|
0.15 gpm
|
30 gpm
|
0.2%
|
2.3%
|
5.0-100 psi
|
3/4 hose/1 npt
|
|
|
011381
|
0,57 lpm
|
114 lpm
|
1:500
|
1:40
|
0,34-6,9 bar
|
3/4 bsp/1 bsp
|
|
Turbo 100 injector Body PN011970D - Two individual dosing ends are offered to be mixed and matched per customer preference.
|
|
0.5%
Lower End
|
011982C
|
|
15 gpm
|
100 gpm
|
0.1%
|
0.5%
|
15-120 psi
|
2 npt
|
|
|
011982C
|
57 lpm
|
379 lpm
|
1:1000
|
1:200
|
1,03-8.3 bar
|
63 mm bsp
|
|
1.0%
Lower End
|
011982D
|
|
15 gpm
|
100 gmp
|
0.5%
|
1.0%
|
15-120 psl
|
2 npt
|
|
|
011982D
|
57 gpm
|
379 lpm
|
1:200
|
1:100
|
1,03-8,3 bar
|
63 mm bsp
|
|
|
|
